| Description |
- The Taimold 274LR Elbow Connector is a fully rated 25kV, 200 Amp
Class loadbreak connector. It includes provisions for energized
operation using standard hotstick tools allowing loadmake/break
operation and a visible disconnect. It has a standard interface for
connecting to 25kV, 200 Amp bushing inserts, junctions and operating
accessories. The 274LR are equipped with an integral voltage test point.
|
| Features |
- 25kV, 200 Amp Loadbreak Elbow
- Fully shielded, fully submersible molded rubber housing.
- 100% peroxide-cured construction includes insulation and conductive
EPDM Materials.
- Non-corrosive, capacitively coupled voltage test point provision
with removable protective cap.
- Provision for hot stick operation.
- Provision for ground wire connection.
- Wide cable range with minimum number of sizes.
- Long bi-metal compression lug is standard.
|
| Applications |
- The 274LR is designed for connecting to and operating 25kV Class,
200 Amp distribution apparatus. It provides a convenient method to
connect/disconnect cable and equipment on power distribution systems.
The 274LR allows connection of cables with insulation diameters from
0.760" (19.3mm) to 1.310" (33.3mm) with only four elbow sizes. (#2
solid, 260 mil to 4/0 stranded, 345 mil)
|
